Small-sized
10.1-inch 800 x 1280
Portrait IPS Display | PCAP Touchscreen Integration
- Model AWY-8001280T101 SERIES
- Size 10.1"
- Resolution 800 x 1280
- Interface MIPI
- Brightness 300 / 400 nits (cd/m2)
- Touch PCAP
- Operating Temp -20 ~ 70 °C
- Viewing Angle IPS
Available options in this category
| Item | Brightness | Interface | Touch | A. Area | O.P. Temp. | Viewing Angle |
| PC02 | 300 | MIPI | CTP | 153.36 x 216.58 | -20 ~ 70 °C | IPS |
Product Overview
Designed for modern smart interfaces, this 10.1-inch WXGA (800x1280) Portrait IPS Display Module combines vivid colors with IPS wide-viewing angles and 400 nits brightness. Integrated with PCAP capacitive touch and a low-power MIPI interface, it supports a reliable operating range of -20°C to 70°C. It is the ideal touch display solution for smart access control, industrial tablets, medical workstations, and interactive self-service kiosks.
