Round Display
4.0-inch 720 x 720
High-Resolution Extreme Wide-Temp Round IPS Display
- Model AWD-720720T40 SERIES
- Size 4.0"
- Resolution 720 x 720
- Interface MIPI
- Brightness 600 nits (cd/m2)
- Touch Optional
- Operating Temp -30 ~ 85 °C
- Viewing Angle IPS
Available options in this category
| Item | Brightness | Interface | Touch | A. Area | O.P. Temp. | Viewing Angle |
| PC01 | 600 | MIPI | CTP | 101.4 x 10.4 | -30 ~ 85 °C | IPS |
Product Overview
Designed for premium circular interfaces and harsh environments, this 4.0-inch Round (720x720) IPS Display Module delivers HD-grade visuals with 600 nits. Featuring a high-speed MIPI interface, an extreme operating temperature range of -30°C to 85°C, and optional touch customization, it is the premier choice for smart home rotary controllers, automotive digital dials, industrial HMIs, and medical workstations.
