Small-sized
10.1-inch 1024 x 600
High-Brightness (up to 1100 nits) Industrial TFT LCD
- Model AWK-1024600T101 SERIES
- Size 10.1"
- Resolution 1024 x 600
- Interface LVDS
- Brightness 480 - 1100 nits (cd/m2)
- Touch RTP / PCAP
- Operating Temp -20 ~70 °C
-
Viewing Angle
IPS
70/70/60/70
Available options in this category
| Item | Brightness | Interface | Touch | A. Area | O.P. Temp. | Viewing Angle |
| N10 | 500 | LVDS | - | 222.72 x 125.28 | -20 ~70 °C | IPS |
| N17 | 1100 | MIPI | - | 222.72 x 125.28 | -30 ~85 °C | IPS |
| P03 | 480 | LVDS | RTP | 222.72 x 125.28 | -20 ~70 °C | 70/70/60/70 |
| PC03A | 500 | LVDS | CTP | 222.72 x 125.28 | -20 ~70 °C | TN:12 |
| PC10 PC13 |
400 1000 |
LVDS RGB |
CTP | 222.72 x 125.28 | -20 ~70 °C | IPS |
Product Overview
Engineered for harsh and outdoor environments, this 10.1-inch WSVGA (1024x600) Industrial TFT LCD Module features ultra-high brightness up to 1100 nits and IPS wide-viewing angles for exceptional sunlight readability. Supporting flexible interfaces (LVDS, MIPI, RGB), an extreme operating range up to -30°C to 85°C, and optional RTP/PCAP touchscreens, it is the ideal display choice for EV chargers, industrial HMIs, medical devices, and smart marine/automotive systems.
