Small-sized
5.0-inch 800 x 480
High-Brightness (up to 1000 nits) Wide-Temp IPS Display with Optional Touch
- Model AWK-800480T50 Series
- Size 5.0"
- Resolution 800 x 480
- Interface RGB / LVDS / SPI
- Brightness 300 - 1000 nits (cd/m2)
- Touch Optional
-
Operating Temp
-20 ~ 70 °C
-30 ~ 85 °C - Viewing Angle IPS
Available options in this category
| Item | Brightness | Interface | Touch | A. Area | O.P. Temp. | Viewing Angle |
| N07 N08 N09 |
300 500 1000 |
RGB | - | 108.0 x 64.8 | -30 ~ 85 °C | IPS |
| N15 | 1000 | LVDS | - | 108.0 x 64.8 | -30 ~ 85 °C | IPS |
| N26 N30A N35 |
1000 | RGB SPI RGB |
- | 108.0 x 64.8 | -30 ~ 85 °C | IPS |
| P08 P09 |
400 800 |
RGB | RTP | 108.0 x 64.8 | -30 ~ 85 °C | IPS |
| PC08 PC09 PC09A |
400 800 1000 |
RGB | CTP | 108.0 x 64.8 | -30 ~ 85 °C | IPS |
| PC15B | 1000 | LVDS | CTP | 108.0 x 64.8 | -30 ~ 85 °C | IPS |
| PC43 | 1000 | SPI | CTP | 108.0 x 64.8 | -30 ~ 85 °C | IPS |
Product Overview
Designed for versatile industrial applications, this 5.0-inch TFT LCD module combines an 800 x 480 resolution with IPS technology for wide viewing angles and consistent visual clarity. Offering RGB, LVDS, and SPI interface options alongside high brightness levels up to 1000 nits, it ensures strong display readability and system flexibility. Built to operate reliably across extended temperatures from -30°C to 85°C with optional touch functionality, it delivers durable performance. This display module provides a practical solution for industrial control panels, outdoor equipment, medical monitors, and automotive displays.
