Small-sized
3.5-inch 320 x 480
TFT LCD Display with PCAP Touch Panel
- Model AWK-320480T35 SERIES
- Size 3.5"
- Resolution 320 x 480
- Interface MIPI
- Brightness 300 nits (cd/m2)
- Touch Optional
- Operating Temp -20 ~ 70 °C
- Viewing Angle 70/70/70/60
Available options in this category
| Item | Brightness | Interface | Touch | A. Area | O.P. Temp. | Viewing Angle |
| N04 | 350 | SPI+RGB | - | 48.96 x 73.44 | -20 ~ 70 °C | IPS |
| PC03 | 250 | MIPI | CTP | 48.96 x 73.44 | -20 ~ 70 °C | 70/70/70/60 |
| PC04A | SPI+RGB | CTP | 48.96 x 73.44 | -20 ~ 70 °C | IPS | |
| PC19 | 800 | SPI | CTP | 48.96 x 73.44 | -20 ~ 70 °C | IPS |
Product Overview
Designed for effective system integration, this 3.5-inch TFT LCD module features a 320 x 480 resolution and a high-speed MIPI interface for efficient data transmission. Delivering 300 nits brightness with optional touch functionality, it offers reliable visual performance and clear display output. Built to operate stably across a wide temperature range from -20°C to 70°C, it provides consistent functionality for diverse environments. This display module serves as a practical solution for medical instruments, IoT terminals, and industrial control equipment.
