Small-sized
4.3-inch 480 x 800
TFT Display with PCAP Touch Panel
- Model AWK-480800T43PC Series
- Size 4.3"
- Resolution 480 x 800
- Interface MIPI
- Brightness 800 nits (cd/m2)
- Touch CTP
- Operating Temp -20 ~ 70 °C
- Viewing Angle IPS
Available options in this category
| Item | Brightness | Interface | Touch | A. Area | O.P. Temp. | Viewing Angle |
| PC11 | 1000 | SPI+RGB | CTP | 56.16 x 93.60 | -20 ~ 70 °C | IPS |
Product Overview
Designed for high-visibility interactive applications, this 4.3-inch portrait TFT LCD module features a 480 x 800 resolution and IPS technology for wide viewing angles and clear image rendering. Integrated with a Capacitive Touch Panel (CTP) and a MIPI interface, it enables smooth touch responsiveness and fast data transmission. Delivering 800 nits high brightness and operating reliably from -20°C to 70°C, it ensures strong optical performance in outdoor settings. This display module offers a functional solution for smart handheld devices, outdoor equipment, and medical control interfaces.
